Autonics ADIO Series ADIO-EI-MA08AN-ILM

List Price:

$991.00

/each

Product Description

Autonics Remote I/o Systems, model ADIO-EI-MA08AN-ILM, from the ADIO Series product line.

Upper level comm. protocol: Ethernet/IP
Lower level comm. protocol: IO-Link ver. 1.1 (port class: Class A)
I/O Number of ports: 8-port
I/O port connector type: M12
I/O Configuration: Digital Input 8-CH, Digital Input/Output 8-CH
Power supply port: 7/8 inch, 5-Pin
I/O specification: NPN
Rated voltage: 24VDC@(=)
Power consumption: 2.4 W (≤216 W)
Supplying current per port: ≤ 2 A/Port
Sensor current (US): ≤ 9 A
Dimension: W 66 × H 215 × D 38 mm
Material: Zinc Die casting
Unit weight (packaged weight): ≈ 700 g (≈ 900 g)
Ambient temperature: -5 to 70℃, Storage: -25 to 70℃ (no freezing or condensation)
Ambient humidity: 35 to 75%RH (no freezing or condensation)
Protection structure: IP67(IEC standard)
