Autonics PTF30 Series PTF30-A5NN-F8

List Price:

$815.00

/each

Product Description

Autonics Pressure Transmitters, model PTF30-A5NN-F8, from the PTF30 Series product line.

Power supply: 15-35VDC @(=)
Output: DC4-20mA 2-wire Low-limit: 3.6mA(-2.5%), high-limit: 21.6mA(+10%)
Accuracy: ±0.2% of F.S.
Environment_Ambient temperature: -20 to 70℃, storage: -20 to 80℃
Environment_Ambient humidity: 0 to 85%RH
Material: Body: aluminum (AlDc.8S), cover O-Ring: buna N, diaphragm: stainless steel 316, connections: stainless steel 316
Explosion class: Ex d IIC T6
Measurement pressure: Absolute pressure
Protection structure: IP67(IEC standard)
Pressure range: 0 to 2MPa
Mounting bracket: Without bracket
Weight: Approx. 1.2kg
Pressure port: G3/8(PF)

Write a Review

Brand:

Autonics Pressure Transmitters, model PTF30-A5NN-F8, from the PTF30 Series product line.

Power supply: 15-35VDC @(=)
Output: DC4-20mA 2-wire Low-limit: 3.6mA(-2.5%), high-limit: 21.6mA(+10%)
Accuracy: ±0.2% of F.S.
Environment_Ambient temperature: -20 to 70℃, storage: -20 to 80℃
Environment_Ambient humidity: 0 to 85%RH
Material: Body: aluminum (AlDc.8S), cover O-Ring: buna N, diaphragm: stainless steel 316, connections: stainless steel 316
Explosion class: Ex d IIC T6
Measurement pressure: Absolute pressure
Protection structure: IP67(IEC standard)
Pressure range: 0 to 2MPa
Mounting bracket: Without bracket
Weight: Approx. 1.2kg
Pressure port: G3/8(PF)
