Autonics ABL Series ABL-HC16PA-NN
Part Number #
AUT1052657

Autonics ABL Series ABL-HC16PA-NN

List Price:
$275.00
/each
Product Description

Autonics I/o Terminal Blocks, model ABL-HC16PA-NN, from the ABL Series product line.

Specifications

  • Applied relay: APAN3124 [MATSUSHITA(Panasonic)]
  • Rated voltage: ≤ 24 VDC@(=)±10 %
  • Current consumption: ≤ 7.4 mA or ≤ 10.1 mA
  • Number of connector pins: 20
  • Number of relay points: 16
  • Terminal type: Screwless
  • Terminal pitch: ≥ 5 mm
  • Indicator: Power indicator: red, operating indicator: blue
  • Applicable cable_Solid wire: Ø 0.6 to 1.25 mm
  • Applicable cable_Stranded wire: AWG 22-18 (0.30 to 0.80 mm²)
  • Insulation resistance: ≥1,000MΩ (at 500VDC megger)
  • Dielectric strength_Between coil-contacts: 3,000VAC 50/60Hz for 1 minute
  • Dielectric strength_Between same contacts: 1,000VAC 50/60Hz for 1 minute
  • Environment_Ambient temperature: -15 to 55℃, storage: -25 to 65℃
  • Environment_Ambient humidity: 35 to 85% RH, storage: 35 to 85% RH
  • Material: CASE, BASE, COVER: PC</br>terminal pin: copper+PA66
  • Protection structure: IP20(IEC standard)
  • Weight: ≈ 173 g (≈ 220 g)

Downloadable Materials
