Autonics B7VA Series B7VA-8KD

List Price:

$292.00

/each

Product Description

Autonics Buzzers, model B7VA-8KD, from the B7VA Series product line.

Sound pressure: ≤ 90 ±10% dB (distance at 1 m)
Signal Input Method: Compatible with NPN and PNP inputs
Audio sources: Alarm: 8 types
Audio file format: -
Memory card: -
SD card format type: -
Indicator: Status indicator: Green / Orange LED
Weight: ≈ 232 g (≈ 301.5 g)
Power supply: 12 - 24 VDC@(=)
Power consumption: 7.2 W
Insulation resistance: ≥ 1,000 MΩ (500VDC@(=) megger)
Dielectric strength: Between the charging part and the case: 500 VAC~ 50 / 60 Hz for 1 min
Vibration: 1.5 mm amplitude at frequency 10 to 55 Hz (for 1 min) in each X, Y, Z direction for 2 hours
Shock: 300 m/s² (≈ 30 G) in each X, Y, Z direction for 3 times
Environment_Ambient temperature: -10 to 55 ℃, Storage: -20 to 65 ℃ (no freezing or condensation)
Environment_Ambient humidity: 35 to 85%RH, Storage: 35 to 85%RH (no freezing or condensation)
Protection structure: IP65 (Front part, IEC standard)
Material: Front cover: ABS, Body: PC
