Autonics ERB Series ERB-A-19S-05/05

Autonics ERB Series ERB-A-19S-05/05

Part Number #

AUT1051044

Autonics ERB Series ERB-A-19S-05/05

List Price:

$43.00

/each

Product Description

Autonics Rotary Encoders, model ERB-A-19S-05/05, from the ERB Series product line.

Specifications

Connection method: Set screw
Material: Aluminum(AL 7075-T6), Alumite surface
Max. allowable revolution: 20000rpm
Max. torque: 1.2N.m(12.17kgf.cm)
Rated torque: 0.6N.m(6.08kgf.cm)
Mounting bolt: M3
Mounting torque: 0.7N.m
Min. allowable misalignment: Ø4mm
Max. allowable misalignment: Ø8mm
Inner diameter of both ends: Ø5mm/Ø5mm
Protection structure: -
Torsional stiffness: 140 N·m/rad
Weight: Approx. 14.9g(approx. 14.4g)

Downloadable Materials

Write a Review

CAD Model
Specifications

Brand:

Autonics Rotary Encoders, model ERB-A-19S-05/05, from the ERB Series product line.

Specifications

Connection method: Set screw
Material: Aluminum(AL 7075-T6), Alumite surface
Max. allowable revolution: 20000rpm
Max. torque: 1.2N.m(12.17kgf.cm)
Rated torque: 0.6N.m(6.08kgf.cm)
Mounting bolt: M3
Mounting torque: 0.7N.m
Min. allowable misalignment: Ø4mm
Max. allowable misalignment: Ø8mm
Inner diameter of both ends: Ø5mm/Ø5mm
Protection structure: -
Torsional stiffness: 140 N·m/rad
Weight: Approx. 14.9g(approx. 14.4g)
