Autonics MGA50S Series MGA50S8-1024-3F-N-5
Part Number #
AUT1051033

Autonics MGA50S Series MGA50S8-1024-3F-N-5

List Price:
$243.00
/each
Product Description

Autonics Rotary Encoders, model MGA50S8-1024-3F-N-5, from the MGA50S Series product line.

Specifications

  • Shaft outer diameter: Ø8mm
  • Max. response frequency: 30kHz
  • Max. allowable revolution: 3000rpm
  • Starting torque: Max. 70gf.cm(max. 0.00686N.m)
  • Resolution: 1024P/R
  • Output code: Gray Code
  • Rotating direction: CW
  • Control output: NPN open collector
  • Power supply: 5VDC @(=) ±5%(ripple P-P: max. 5%)
  • Connection type: Axial cable type
  • Protection structure: IP50
  • Electrical specification_Output_Positioning error: ±1-bit(LSB: Least Significant Bit)
  • Electrical specification_Output_Output phase/Output angle: TS: 0.703°±15'(10-bit)
  • Environment_Ambient temperature: -10 to 70℃, storage: -25 to 85℃
  • Environment_Ambient humidity: 35 to 85% RH, storage: 35 to 90% RH
  • Accessories: Bracket, Coupling
  • Weight: Approx. 400g(approx. 270g)

Downloadable Materials

Write a Review

Out of stock

Request a Quote
  • CAD Model
  • Specifications
Brand:

Autonics Rotary Encoders, model MGA50S8-1024-3F-N-5, from the MGA50S Series product line.

Specifications

  • Shaft outer diameter: Ø8mm
  • Max. response frequency: 30kHz
  • Max. allowable revolution: 3000rpm
  • Starting torque: Max. 70gf.cm(max. 0.00686N.m)
  • Resolution: 1024P/R
  • Output code: Gray Code
  • Rotating direction: CW
  • Control output: NPN open collector
  • Power supply: 5VDC @(=) ±5%(ripple P-P: max. 5%)
  • Connection type: Axial cable type
  • Protection structure: IP50
  • Electrical specification_Output_Positioning error: ±1-bit(LSB: Least Significant Bit)
  • Electrical specification_Output_Output phase/Output angle: TS: 0.703°±15'(10-bit)
  • Environment_Ambient temperature: -10 to 70℃, storage: -25 to 85℃
  • Environment_Ambient humidity: 35 to 85% RH, storage: 35 to 90% RH
  • Accessories: Bracket, Coupling
  • Weight: Approx. 400g(approx. 270g)
